DISCOVER WHAT MAKES US UNIQUE

Sonus faber is a designer and manufacturer of high-end audio equipment.
Latin for “Artisan of Sound”, Sonus faber combines 40 years of audio engineering
with signature Italian design. Sonus faber speakers are handcrafted in Vicenza, Italy
from organic materials such as wood and leather, producing the signature “natural sound”:
three-dimensional, immersive audio, reproduced as the artist intended.

reference
faber reference.JPG
Sonus faber
fab crem 1.JPG
Cremonese
Sonus faber

THE STRADIVARI'S VIOLIN

Inspired by the shape of Lilium, Il Cremonese is a tribute to the most famous creation of Antonio Stradivari. Its five non-parallel walls structure and the sides applied on the enclosure, requires a careful processing techniques, as for a musical instrument: from the wood bending and shaping, to the treatments of the precious Avional surfaces.

Sonus faber

SYSTEM

3.5 way, full para-aperiodic vented box

LOUDSPEAKERS

Tw: H28 XTR-04 DAD Arrow Point, Ø 28 mm
Md: M18 XTR-04 Neodymium Magnet System, Ø 180 mm
W: 2 x W18XTR-12, Ø 180 mm
Sw: 2 x W22XTR-16, Ø 220 mm

CROSSOVER

80Hz - 250Hz - 2500Hz

FREQUENCY RESPONSE

25 Hz – 35.000 Hz, tuning port included

SENSITIVITY

92 db SPL (2.83V/1 m)

NOMINAL IMPEDANCE

4 ohm

SUGGESTED AMPLIFIER POWER OUTPUT

100W – 800W, without clipping

DIMENSIONS (HXWXD)

1449 x 398 x 621 mm
57 x 15,6 x 24.5 in

WEIGHT

84 Kg ea – net weight
185 lb ea – net weight

Faber aida 3.JPG
Aida
Sonus faber
Sonus faber

ELEGANCE AND PRECISION

Aida, that takes its name from the most grandiose Opera by Giuseppe Verdi, is the pinnacle of the Sonus faber catalogue born from the heart of the team and combines tradition with technological innovation, sophistication with power.

Sonus faber

SYSTEM

“3 and 2/3” way, Sound field Shaper technology, “Zero Vibration Transmission™” technology, para-aperiodic vented box “Stealth Ultraflex System™” and staggered low frequency floor standing loudspeaker system

LOUDSPEAKERS

Tw: H28 XTR-04 DAD Arrow Point, Ø 28 mm
Md: M18 XTR-04 Neodymium Magnet System, Ø 180 mm
W: 2 x W22XTR-12 Fe Magnet System, Ø 220 mm
Sw: SW32XTR-08 Long Throw, Fe Magnet System, Ø 320 mm

SOUND FIELD SHAPER

Tw: 29XTR2 DAD Arrow Point, Ø 29 mm
Md: 2 x M8XTR, Ø 80 mm

CROSSOVER

55Hz - 150Hz - 200Hz – 3000Hz

FREQUENCY RESPONSE

18 Hz – 35.000 Hz, Stealth Ultraflex™ included

SENSITIVITY

92 db SPL (2.83V/1 m)

NOMINAL IMPEDANCE

4 ohm

POWER HANDLING

100W – 1KW, without clipping

DIMENSIONS (HXWXD)

1725 x 482 x 780 mm
68 x 19 x 31 in

WEIGHT

165 Kg ea – net weight
363 lb ea – net weight

Lilium
Faber lilium 2.jpg
Sonus faber

THE SONUS FABER SIGNATURE STYLE

The idea of the dual curvature of the cabinet sides, firstly conceptualized with the Sonus faber and evolved in Aida, is here enhanced thanks to a new design that reinvents the ``lyra`` outline merging two separate identities that cooperate inside the same shape.

Sonus faber

SYSTEM

3.5 way para-aperiodic vented box

LOUDSPEAKERS

Tw: H28 XTR-04 DAD Arrow Point, Ø 28 mm
Md: M18 XTR-04 Neodymium Magnet System, Ø 180 mm
W: 3 x W18XTR-16, Ø 180 mm
Sw: SW26 XT-08, Ø 260 mm

CROSSOVER

80Hz - 250Hz – 2,500Hz

FREQUENCY RESPONSE

20 Hz – 35.000 Hz, Stealth reflex included

SENSITIVITY

92 db SPL (2.83V/1 m)

NOMINAL IMPEDANCE

4 ohm

SUGGESTED AMPLIFIER POWER OUTPUT

100 – 800 W, without clipping

DIMENSIONS (HXWXD)

1600 x 491 x 705 mm
63 x 19,3 x 27,7 in

WEIGHT

103 Kg ea - net weight
227 Ib ea - net weight
156 Kg ea – shipping weight
344 lb ea – shipping weight

fab olym 1.JPG
olympica
fab olym back 2.JPG
Sonus faber

ESSENCE OF A BRAND

Since 1983, many moments have marked the history of Sonus faber; the launch of the Olympica Collection 6 years ago is one of them. One of the first lines presented as a complete family of products, but above all, the very first one to feature original drivers, entirely designed in Sonus faber.
Olympica Nova is the second generation of the iconic family of 2013, improved in its form and substance, imbued with the timeless values that inspired us in creating the original line.
The result is a new Collection that embraces the most advanced technologies that already enhance our most prestigious creations.

Sonus faber

SYSTEM

3 way, full para-aperiodic vented box “Stealth Ultraflex”, floorstanding loudspeaker system.

LOUDSPEAKERS

Tw: H28 XTR3, Neodymium “cup design” motor system with DAD™, Ø 28 mm
Md: M15 XTR2-04, CCAW wire on a “eddy current free” voice coil, Ø 150 mm
W: 3 x W18XTR2-12, Ø 180 mm

CROSSOVER

250 Hz - 2.500 Hz

FREQUENCY RESPONSE

32 Hz – 35.000 Hz

SENSITIVITY

90 dB SPL (2.83V/1 m)

NOMINAL IMPEDANCE

4 ohm

SUGGESTED AMPLIFIER POWER OUTPUT

60 W – 400 W, without clipping

DIMENSIONS (HXWXD)

1174,5 x 424 x 529,8 mm
46.3 x 16.7 x 20.8 in

WEIGHT

44 Kg ea – net weight
97 Ib ea – net weight

fab olym 3.JPG
Sonus faber

ESSENCE OF A BRAND

Since 1983, many moments have marked the history of Sonus faber; the launch of the Olympica Collection 6 years ago is one of them. One of the first lines presented as a complete family of products, but above all, the very first one to feature original drivers, entirely designed in Sonus faber.
Olympica Nova is the second generation of the iconic family of 2013, improved in its form and substance, imbued with the timeless values that inspired us in creating the original line.
The result is a new Collection that embraces the most advanced technologies that already enhance our most prestigious creations.

Sonus faber

SYSTEM

3 way, full para-aperiodic vented box “Stealth Ultraflex”, floorstanding loudspeaker system.

LOUDSPEAKERS

Tw: H28 XTR3, Neodymium “cup design” motor system with DAD™, Ø 28 mm
Md: M15 XTR2-04, CCAW wire on a “eddy current free” voice coil, Ø 150 mm
W: 2 x W18XTR2-08, Ø 180 mm

CROSSOVER

250 Hz - 2.500 Hz

FREQUENCY RESPONSE

35 Hz – 35.000 Hz

SENSITIVITY

90 dB SPL (2.83V/1 m)

NOMINAL IMPEDANCE

4 ohm

SUGGESTED AMPLIFIER POWER OUTPUT

50 W – 300 W, without clipping

DIMENSIONS (HXWXD)

1104,5 x 376 x 459,8 mm
43.5 x 14.8 x 18.1 in

WEIGHT

35 Kg ea – net weight
77.1 Ib ea – net weight

fab olym 4b.jpg
Sonus faber

ESSENCE OF A BRAND

Since 1983, many moments have marked the history of Sonus faber; the launch of the Olympica Collection 6 years ago is one of them. One of the first lines presented as a complete family of products, but above all, the very first one to feature original drivers, entirely designed in Sonus faber.
Olympica Nova is the second generation of the iconic family of 2013, improved in its form and substance, imbued with the timeless values that inspired us in creating the original line.
The result is a new Collection that embraces the most advanced technologies that already enhance our most prestigious creations.

Sonus faber

SYSTEM

3 way, full para-aperiodic vented box “Stealth Ultraflex”, floorstanding loudspeaker system.

LOUDSPEAKERS

Tw: H28 XTR3, Neodymium “cup design” motor system with DAD™, Ø 28 mm
Md: M15 XTR2-04, CCAW wire on a “eddy current free” voice coil, Ø 150 mm
W: W18XTR2-04, Ø 180 mm

CROSSOVER

250 Hz - 2.500 Hz

FREQUENCY RESPONSE

40 Hz – 35.000 Hz

SENSITIVITY

88 dB SPL (2.83V/1 m)

NOMINAL IMPEDANCE

4 ohm

SUGGESTED AMPLIFIER POWER OUTPUT

50 W – 250 W, without clipping

DIMENSIONS (HXWXD)

1036,5 x 359,7 x 422,5 mm
40.8 x 14.2 x 16.6 in

WEIGHT

30,7 Kg ea – net weight
67.6 Ib ea – net weight
